GM Load Cell GML-DHH4ZS



The robust and well-designed load cell from General Measure, with the C2/C3 grade accuracy. GML-DHH4ZS canister load cell has the material option of alloy steel and stainless steel. It is compact and easy to install. The weighing capacity is from 10000kg to 50000kg, which is usually used for floor scale, truck scale, railway scale, silo scales, and tank scale. It can fulfill a wide range of industries that require accurate measurements, avoiding product waste and saving costs.

ENQUIRE

PRODUCT ENQUIRE


Weighing Capacity

  • 10000kg
  • 15000kg
  • 20000kg
  • 30000kg
  • 40000kg
  • 50000kg



IP68



Operating Functions

  • Self-restoring due to pendulum bearing
  • Optimized for parallel connection by corner pre-adjustment



Multiple Applications

  • Hopper scale
  • Belt scale
  • Batching scale
