GM PaxGo Series Bagging Scale 50kg Pneumatic Version



Intelligent Bagging Scale with High Speed and Efficiency

The pneumatic version of the PaxGo bagging scale is designed to fulfill high-speed packing needs, which can reach above 1100pcs/h. It is designed for the big bag packing machine for plastic particles, rice, sugar, and other granular materials.

ENQUIRE
  • IP 65

    IP 65

  • High Accuracy

    High Accuracy

  • CE Approve

    CE Approve

PRODUCT ENQUIRE


Granular Materials

  • design for the big bag packing machine for plastic particles, rice, sugar, and other granular material;

Easy Installation

  • module design, easy for installation and dismount;

Convenient Setup

  • self-adjust function with target value set only;

High-speed Performance

  • pneumatic cylinder control, speed can reach above 1100pcs/h;

Weighing Accurate

  • weighing range is 25-50kg, accuracy is ±25g.
