Weighing Transmitter GMT-P1
The GMT-P1 is a panel-mounted weighing transmitter that offers exceptional reliability, advanced filtering, and tested ability to perform stably under the interference of harsh industrial environments. It is customized for dynamic weighing systems with the highest demand for reliability, response speed, and accuracy.
ENQUIRE
IP 65
High Accuracy
Anti-Vibration
CE Approve
Compact Design
Advanced Digital Filtering
PRODUCT ENQUIRE
OIML Approval
Hardware
Standard:
- RS232 or RS485 selectable by switch;
- I input 2 outputs I/O
Options:
- Single network port supports Modbus TCP/IP;
- Dual network ports support Modbus TCP/IP (No serial ports);
- Profinet or Ethernet IP or Ethercat or CCLink IE (No serial ports);
- Analog output.
Easy to use
- Selectable RS232/485 interface by switch.
- Simple design to facilitate connection to a PLC.
- Operating functions by 4 set buttons.
- I/O points (1 input, 2 outputs) as standard.
Flexible Operation with Stable Performance
- Optional analog output (0-5V initial).
- Powers up to 8units of load cells with 6 wires connection, provide long distance compensation.
- Selectable A/D Converter 30/60/120/240/480/960times/sec.
- 1,000,000 weight resolution ability, with second generation Vibration Cancellation Filter.
- Support theoretical calibration with loadcell sensitivity.
Compact Design
- Compact, lightweight body makes it ideal for mounting into a control panel.
 |
 |
 |
