Weighing Transmitter GM7702



Digital Weighing Transmitter with RS232/485 and analogue output

GM7702, a digital weighing transmitter with the standard dimension, is suitable for mounting on DIN rail in many industrial fields. Small size and flat compact design make it ideally integrate with whole weighing sector. Due to its high practicability, stability and easy operation, GM7702 can be widely applied to the industry of feeds, chemical, concrete and bitumen mixing, metallurgy smelting, etc..

ENQUIRE
  • IP 65

    IP 65

  • EMC Testing Passed

    EMC Testing Passed

  • CE Approve

    CE Approve

  • Compact Design

    Compact Design

  • I/O Programmable

    I/O Programmable

PRODUCT ENQUIRE


Easy to Use

  • With RS232/485 serial ports and support remote control
  • Support tare, preset tare function
  • Equipped with 2 IN 3 OUT I/O module

Compact Design

  • Small size and flat compact design with standard 35mm DIN mounting.

Flexible Setting

  • High Precision: A/D converter 120/240/480 times/sec.
  • Optional 16bit high-precision analog output: 0~24mA, 0~5V, 0~10V and user-defined analog output.
